Rec. 2020 leads the future of color reproduction and covers 75.8% of all colors visible to human eyes. This color space standard, created for Ultra HD (both 4K and 8K formats), delivers more than double the color range compared to the older Rec. 709 standard that only manages 35.9% of the visible spectrum.

The difference between Rec. 709 and Rec. 2020 color space shows remarkable progress in display technology. Rec. 709 served as the HDTV standard, but Rec. 2020's capabilities go much further with Laser TVs. The new standard supports 10-bit and 12-bit color depth, which provides over a billion possible color variations. These enhanced color reproduction capabilities provide a valuable means for content creators to achieve better results, delivering more vibrant and lifelike visual experiences.

Let's get into everything about the Rec. 2020 standard, from technical specifications to practical applications. The RGB primaries, signal encoding methods, and comparisons with other color standards paint a complete picture. Furthermore, the industry's adoption timeline provides insight into the future of visual content.

ITU-R BT.2020 Specification Overview

The International Telecommunication Union (ITU) published the ITU-R Recommendation BT.2020 (Rec. 2020) in August 2012. This complete standard defines parameters for ultra-high-definition television (UHDTV) systems to produce and exchange programs internationally. The ITU has released updated versions since then, with BT.2020-2 receiving approval in October 2015.

Rec. 2020 forms the foundations of UHD content and establishes specifications in video technology of all types. The standard focuses on two resolution formats: 3840×2160 pixels (4K) and 7680×4320 pixels (8K). Both maintain a 16:9 aspect ratio with square pixels. These higher resolutions want to give viewers "an increased sense of 'being there' and an increased sense of realness".

The standard supports progressive scan with various frame rates: 120Hz, 100Hz, 60Hz, 50Hz, 30Hz, 25Hz, 24Hz, and their fractional variants (like 59.94Hz). Modern displays have moved away from interlaced scanning to represent motion more smoothly.

Rec. 2020 defines signal encoding parameters that ensure accurate color reproduction. RGB and YCbCr signal formats work with various chroma subsampling options (4:4:4, 4:2:2, and 4:2:0). The standard introduces constant luminance encoding (Y'CC'BCC'RC) and conventional non-constant luminance (Y'C'BC'R).

The standards committee chose color primary coordinates at the visible color space's extreme edge. These monochromatic light sources match specific wavelengths: 630nm (red), 532nm (green), and 467nm (blue). D65 serves as the reference white point and approximates average daylight at around 6500 Kelvin.

Current display technologies don't deal very well with reproducing the entire Rec. 2020 color gamut. This raises a question in research: What makes color primaries Rec. 2020-compliant? Some researchers call displays compliant if they are "perceptually indistinguishable from a true Rec. 2020 display".

Manufacturers and content creators who implement Rec. 2020 get specific values for the non-linear transfer function. The 10-bit systems use α = 1.099 and β = 0.018, while 12-bit systems need slightly different values (α = 1.0993 and β = 0.0181). These parameters ensure consistent visual experiences across devices and viewing environments.

Rec. 2020 Color Space Parameters

The exceptional color reproduction capabilities of Rec. 2020 rely on three key parameters that distinguish it from older standards like Rec. 709. These parameters define how the color space captures and displays the visible spectrum, serving as the foundation for next-generation ultra-high-definition content. Devices like the Valerion VisionMaster Pro 2, a 4K RGB triple laser projector, exemplify the practical application of these parameters.

RGB Primaries: 630nm, 532nm, 467nm Wavelengths

The Rec. 2020 color space stands out from earlier standards by using RGB primaries that match monochromatic light sources on the CIE 1931 spectral locus. This approach shows colors in their purest form. Each primary matches a specific wavelength: 630nm for red, 532nm for green, and 467nm for blue.

These primaries have precise CIE 1931 xy chromaticity coordinates: (0.708, 0.292) for red, (0.170, 0.797) for green, and (0.131, 0.046) for blue. Engineers chose these wavelengths carefully. They allow Rec. 2020 to cover 99.9% of Pointer's gamut in the xy chromaticity diagram.

A fascinating detail emerges - the primaries in the Rec. 2020 standard mirror those Maxwell proposed in the 19th century. The green primary could reach 100% optimum coverage at 527nm. However, 532nm proved more practical with current LED and laser technologies.

White Point Reference: Illuminant D65

Rec. 2020 and Rec. 709 both use Illuminant D65 as their white point reference. This white point sits at coordinates (0.3127, 0.3290) on the CIE 1931 xy chromaticity diagram. D65 illuminant matches average daylight at roughly 6500 Kelvin.

The shared white point between standards helps convert between color spaces easily. Users get consistent color perception across different content types. Even with their vastly different color gamut sizes, both standards share this common white reference point.

CIE 1931 Coverage: 75.8% vs Rec. 709's 35.9%

The biggest difference between what is Rec. 2020 and what is Rec. 709 shows in their visible color spectrum coverage. Rec. 2020 reaches an impressive 75.8% of the CIE 1931 color space. Rec. 709 only manages 35.9%[111]. Simply put, the Rec. 2020 color space offers double the color range of its predecessor.

This bigger gamut creates richer and more vibrant colors. The DCI-P3 digital cinema color space covers 53.6%, while Adobe RGB reaches 52.1% of the CIE 1931 color space. Rec. 2020 outperforms not just Rec. 709 but also other professional color spaces.

The CIE 1931 chromaticity diagram makes this clear - Rec. 2020 creates a larger triangle that contains the smaller Rec. 709 triangle. This visual clearly shows why Rec 709 vs Rec 2020 comparisons always highlight Rec. 2020's better color reproduction abilities.

Signal Encoding and Transfer Functions

Transfer functions are vital to how the Rec. 2020 color space converts captured images to displayed ones. A good grasp of these functions shows how the standard handles signal encoding and processing.

Video systems rely on three primary transfer functions. Opto-Electronic Transfer Function (OETF) turns scene light into electronic signals in cameras. Electro-Optical Transfer Function (EOTF) changes electronic signals to display light. Opto-Optical Transfer Function (OOTF) shows the relationship between captured and displayed light.

What is Rec 2020 uses almost the same non-linear transfer function as what is Rec 709 mathematically. All the same, 12-bit systems benefit from higher precision parameters. The function looks like this:

For 10-bit systems: α = 1.099 and β = 0.018 (similar to Rec. 709). For 12-bit systems: α = 1.0993 and β = 0.0181 (higher precision)

Comparing Rec. 709 and Rec. 2020, both standards utilize gamma-based transfer functions. The reference display for Rec. 2020 content uses a gamma 2.4 transfer function as defined in ITU-R BT.1886.

Modern implementations often combine the Rec. 2020 color space with high dynamic range (HDR) transfer functions from Rec. 2100, thereby moving beyond the standard dynamic range (SDR). These functions include:

1. Perceptual Quantizer (PQ): SMPTE ST 2084 standardization allows brightness levels up to 10,000 cd/m²
2. Hybrid Log-Gamma (HLG): BBC and NHK developed this for backward compatibility with SDR displays

HDR displays process video at 10 bits per color component instead of 8 bits, which creates more steps between minimum and maximum brightness.

Rec. 2020's support for both constant and non-constant luminance encoding methods stands out. Traditional systems like Rec. 709 apply gamma correction to RGB signals before calculating luminance (Y)—creating "non-constant luminance." This method slightly differs from true luminance. The standard has provisions for both approaches, recognizing their unique advantages and limitations.

Rec. 2020 delivers better encoding efficiency through RGB and YCbCr signal formats for color difference encoding. The constant luminance version (YcCbcCrc) handles limitations in traditional non-constant approaches better, especially with wide color gamut content.

This framework helps Rec. 2020 color space deliver excellent visual quality in display technologies of all types while keeping signal processing requirements reasonable.

Supported Formats and Subsampling Schemes

Rec. 2020 color space supports multiple signal formats and subsampling schemes that boost its flexibility in broadcasting applications of all types, beyond its expanded color gamut.

RGB and YCbCr Signal Formats

Rec. 2020 works with both RGB and YCbCr signal formats using full-resolution 4:4:4 sampling. RGB format keeps red, green, and blue channels separate. YCbCr splits image luminance (Y) from chrominance components (Cb and Cr). Broadcasting benefits from YCbCr because it lets you allocate bandwidth based on how humans perceive images.

What is Rec 2020 uses specific weighting coefficients for YCbCr signals: KR = 0.2627, KG = 0.678, and KB = 0.0593. These coefficients differ from those in Rec 709, which reflects the newer standard's wider color gamut.

4:4:4, 4:2:2, and 4:2:0 Chroma Subsampling

Human eyes respond more to brightness changes than color differences, and chroma subsampling takes advantage of this. Rec 2020 color space supports three central subsampling schemes:

• 4:4:4: Full color resolution stays intact for maximum quality without subsampling.
• 4:2:2: Bandwidth is reduced by about one-third as chroma components are sampled at half the horizontal resolution.
• 4:2:0: Bandwidth drops by roughly 50% because chroma components are sampled at half the horizontal and vertical resolution.

The notation (4:x:y) shows a conceptual region 4 pixels wide and 2 pixels high. "x" represents chroma samples in the first row, while "y" indicates chroma sample changes between rows.

YcCbcCrc for Constant Luminance Encoding

Rec 2020 leads major standards by introducing constant luminance encoding through the YcCbcCrc format. Traditional YCbCr calculates luminance after gamma correction, creating "non-constant luminance". YcCbcCrc takes a different approach by applying gamma correction after calculating the luminance.

YcCbcCrc's main advantage lies in its better luminance information retention. This method is most effective when you require precise luminance preservation over compatibility with existing standards.

The Final Thought

Rec. 2020 represents a major leap forward in color reproduction technology without doubt. This piece has shown how this Ultra HD color space standard delivers more than double the color range of its predecessor. The coverage reaches an impressive 75.8% of the visible spectrum compared to Rec. 709's 35.9%. The support for 10-bit and 12-bit color depths creates over a billion possible color variations that result in smoother gradients and more realistic images.

The differences between Rec. 2020 and Rec. 709 go beyond the color gamut. The new standard works seamlessly with 4K and 8K resolutions, supporting HDR formats such as HDR10, Dolby Vision, and HLG. Regular displays still cannot reproduce the complete Rec. 2020 gamut. We have a long way to go, but we can build on this progress as quantum dot, laser backlight, and OLED technologies reach 90-98% coverage. An advanced laser projector, such as the Valerion VisionMaster Pro 2, can achieve approximately 110% of the Rec. 2020 gamut, pushing the boundaries of color fidelity in consumer displays. The gap between human eye perception and screen display capabilities keeps shrinking as standards like Rec. 2020 expand color reproduction technology.
